SENSORES DE PROXIMIDAD (Inductivos y Capacitivos) Comus

CODIGO	TIPO	Tipo de rosca (mm)	Distancia de sensado (mm)	Tipo de salida	Tensión de alimentación
PIP-T5S-001	INDUCTIVOS	M5	1	PNP/NO	10-30 VDC 3CABLES
PIN-T5S-001		M5	1	NPN/NO	10-30 VDC 3CABLES
PID-T8L-001		M8	1	DC/NO	10-30 VDC 2CABLES
PID-T8L-011		M8	1	DC/NC	10-30 VDC 2CABLES
PIN-T8S-001		M8	1	NPN/NO	10-30 VDC 3CABLES
PIP-T8S-001		M8	1	PNP/NO	10-30 VDC 3CABLES
PIP-T8S-002		M8	2	PNP/NO	10-30 VDC 3CABLES
PIA-T12L-001		M12	2	AC/NO	90-250 VAC 2CABLES
PIA-T12L-011		M12	2	AC/NC	90-250 VAC 2CABLES
PID-T12L-001		M12	2	DC/NO	10-30 VDC 2CABLES
PID-T12L-011		M12	2	DC/NC	10-30 VDC 2CABLES
PIN-T12S-001		M12	2	NPN/NO	10-30 VDC 3CABLES
PIN-T12S-021		M12	2	NPN/NO + NC	10-30 VDC 4CABLES
PIP-T12S-001		M12	2	PNP/NO	10-30 VDC 3CABLES
PIP-T12S-021		M12	2	PNP/NO + NC	10-30 VDC 4CABLES
PIA-S17-001		P17	5	AC/NO	90-250 VAC 2CABLES
PIA-S17-011		P17	5	AC/NC	90-250 VAC 2CABLES
PID-S17-001		P17	5	DC/NO	10-30 VDC 2CABLES
PID-S17-011		P17	5	DC/NC	10-30 VDC 2CABLES
PIN-S17-001		P17	5	NPN/NO	10-30 VDC 3CABLES
PIN-S17-021		P17	5	NPN/NO + NC	10-30 VDC 4CABLES
PIP-S17-001		P17	5	PNP/NO	10-30 VDC 3CABLES
PIP-S17-021		P17	5	PNP/NO + NC	10-30 VDC 4CABLES
PIA-T18L-001		M18	5	AC/NO	90-250 VAC 2CABLES
PIN-T18S-001		M18	5	NPN/NO	10-30 VDC 3CABLES
PIN-T18S-021		M18	5	NPN/NO + NC	10-30 VDC 4CABLES
PID-S18-001		P18	5	DC/NO	10-30 VDC 2CABLES
PID-S18-011		P18	5	DC/NC	10-30 VDC 2CABLES
PIN-S18-001		P18	5	NPN/NO	10-30 VDC 3CABLES
PIP-S18-001		P18	5	PNP/NO	10-30 VDC 3CABLES
PID-T30L-001		M30	10	DC/NO	10-30 VDC 2CABLES
PIN-T30L-021		M30	10	NPN/NO + NC	10-30 VDC 4CABLES
PIN-T30S-001		M30	10	NPN/NO	10-30 VDC 3CABLES
PIN-T30L-022		M30	15	NPN/NO + NC	10-30 VDC 4CABLES
PIP-T30S-001		M30	10	PNP/NO	10-30 VDC 3CABLES
PCN-T12L-002	CAPACITIVOS	M12	4	NPN/NO	10-30 VDC 3 Cables
PCP-T12L-002		M12	4	PNP/NO	10-30 VDC 3 Cables
PCP-T30L-022		M30	15	PNP/NO+NC	10-30 VDC 4 Cables
PCN-T30L-022		M30	15	NPN/NO+NC	10-30 VDC 4 Cables
