Módulos IGBt



Borrar resultados
Haga click aqui para ver los esquemas...

CODIGO MARCA TIPO CONFIGURACION I (A)
25°C
I (A)
80°C
Vces (V) td(on) (uS)
typ.
td(off) (uS)
typ.
Esquema DIMENSIONES (AxLxH)(mm)
CM50E3Y-24EPOWEREXIGBtSINGLE50 -12000.10.2 1A34x94x31
CM75E3Y-12EPOWEREXIGBtSINGLE75 -6000.150.4 1A48x94x31
CM150E3Y-12EPOWEREXIGBtSINGLE150 -6000.40.6 1A48x94x31
CM200HA-12HPOWEREXIGBtSINGLE200 -6000.40.4 162x107x36
CM200HA-24HPOWEREXIGBtSINGLE200 -12000.250.35 162x107x36
CM300HA-12HPOWEREXIGBtSINGLE300 -6000.350.3 162x107x36
CM300HA-24HPOWEREXIGBtSINGLE300 -12000.250.35 162x107x36
1MBI300S-120POWEREXIGBtSINGLE400 3001200 0.350.45 162x107x36
CM400HA-12HPOWEREXIGBtSINGLE400 -6000.350.35 162x107x36
CM400HA-24HPOWEREXIGBtSINGLE400 -1200 0.30.35 162x108x36
CM600HA-12HPOWEREXIGBtSINGLE600 -6000.350.35 180x110x36
CM600HA-24HPOWEREXIGBtSINGLE600 - 12000.30.45 180x110x36
CM600HA-28HPOWEREXIGBtSINGLE600 -14000.350.5 182x108x36
1MBI600U4B-120FUJIIGBtSINGLE800600 12000.320.41 180x110x36
CM50DY-12HPOWEREXIGBtDUAL50 -6000.20.2 234x94x31
CM50DY-24HPOWEREXIGBtDUAL50 -12000.080.15 234x94x31
CM75DU-12F*POWEREXIGBtDUAL75 -6000.10.3 248x94x31
GA75TS60UI.R.IGBtDUAL75-600 0.110.25 234x94x30
FMG2G75US60FAIRCHILDIGBtDUAL75 -6000.020.07 235x93x32
2MBI75U4A-120FUJIIGBtDUAL100751200 0.320.41 234x92x30
2MBI100TA-060FUJIIGBtDUAL100 600 0.40.4 234x92x30
CM100DY-12HPOWEREXIGBtDUAL100 -6000.120.2 234x94x31
CM100DY-24HPOWEREXIGBtDUAL100 -12000.250.35 248x94x30
2MBI150TA-060FUJIIGBtDUAL150 600 0.40.55 234x92x30
CM150DU-12F *POWEREXIGBtDUAL150 -6000.120.35 248x94x30
CM150DY-12HPOWEREXIGBtDUAL150 -6000.20.3 248x94x30
2MBI150U2A-060FUJIIGBtDUAL150 -6000.40.48 234x92x30
2MBI100U4A-120FUJIIGBtDUAL1501001200 0.320.41 234x92x30
CM150DY-24HPOWEREXIGBtDUAL150 -12000.20.3 248x94x30
IRGTI140U06INT. RECTIFIERIGBtDUAL170 1106000.070.18 234x94x31
CM200DY-12HPOWEREXIGBtDUAL200 -6000.20.3 248x94x30
2MBI200U2A-060FUJIIGBtDUAL200 -6000.40.48 234x92x30
CM200DY-24HPOWEREXIGBtDUAL200 -1200 0.250.3 262x110x31
2MBI150U4A-120FUJIIGBtDUAL2001501200 0.320.41 234x92x30
CM300DY-12HPOWEREXIGBtDUAL300 -6000.350.35 248x94x30
2MBI300U2B-060FUJIIGBtDUAL300 -6000.40.48 245x92x30
CM300DY-24HPOWEREXIGBtDUAL300 -12000.250.35 280x110x36
2MBI200U4B-120FUJIIGBtDUAL3002001200 0.320.41 248x94x31
2MBI200U4H-120FUJIIGBtDUAL3002001200 0.320.41 262x108x30
2MBI300VN-120FUJIIGBtDUAL-3001200 0.551 262x150x21
BSM200GB170DLCEUPECIGBtDUAL400 20017000.10.8 262x108x31
CM400DY-12HPOWEREXIGBtDUAL400 -6000.350.35 262x108x31
2MBI400U2B-060FUJIIGBtDUAL400 -6000.400.48 245x92x30
2MBI300U4H-120FUJIIGBtDUAL4003001200 0.320.41 262x108x30
2MBI400U4H-120FUJIIGBtDUAL6004001200 0.320.41 262x108x30
2MBI600U2E-060FUJIIGBtDUAL600 -6000.40.48 280x110x30
2MBI600VN-120FUJIIGBtDUAL-6001200 0.550.1 262x150x20
CM15TF-12HPOWEREXIGBtSIX: 3 PHASE BRIDGE15 -6000.120.2 339x90x22
CM15TF-24HPOWEREXIGBtSIX: 3 PHASE BRIDGE15 -12000.10.15 345x107x28
CM20TF-12HPOWEREXIGBtSIX: 3 PHASE BRIDGE 20 -6000.120.2 339x90x22
6MBI15S-120FUJIIGBtSIX: 3 PHASE BRIDGE 251512000.350.45 345x107x20
CM30TF-12HPOWEREXIGBtSIX: 3 PHASE BRIDGE30 -6000.120.2 345x107x28
CM30TF-24HPOWEREXIGBtSIX: 3 PHASE BRIDGE30 -12000.10.15 356x127x26
6MBI25S-120FUJIIGBtSIX: 3 PHASE BRIDGE 352512000.350.45 345x107x20
CM50TF-12HPOWEREXIGBtSIX: 3 PHASE BRIDGE50 - 6000.20.2 356x127x26
CM50TF-24HPOWEREXIGBtSIX: 3 PHASE BRIDGE50 -12000.080.15 391x102x30
6MBI35S-120FUJIIGBtSIX: 3 PHASE BRIDGE 503512000.350.45 345x107x20
6MBI50VA-120FUJIIGBtSIX: 3 PHASE BRIDGE -5012000.390.53 345x107x20
CM75TF-12HPOWEREXIGBtSIX: 3 PHASE BRIDGE75 -600 0.120.2 374x91x31
6MBI75S-060FUJIIGBtSIX: 3 PHASE BRIDGE 75-6000.450.4 362x122x20
6MBI75S-120FUJIIGBtSIX: 3 PHASE BRIDGE 100751200 0.350.45 362x122x20
6MBI75U4A-120FUJIIGBtSIX: 3 PHASE BRIDGE 1007512000.320.41 345x107x20
CM100TF-12HPOWEREXIGBtSIX: 3 PHASE BRIDGE100 -600 0.120.2 391x102x31
6MBI100S-060FUJIIGBtSIX: 3 PHASE BRIDGE100 -6000.450.4 362x122x20
6MBI100L-060FUJIIGBtSIX: 3 PHASE BRIDGE100 -6000.50.6 386x94x26
CM150TF-12HPOWEREXIGBtSIX: 3 PHASE BRIDGE 150 -6000.20.3 3102x107x32
6MBI100S-120FUJIIGBtSIX: 3 PHASE BRIDGE 15010012000.350.45 362x122x20
6MBI100U4B-120FUJIIGBtSIX: 3 PHASE BRIDGE 15010012000.320.41 362x122x20
7MBR25UA-120FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 251512000.410.37 445x107x20
7MBR30U2A-060FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 30-6000.360.45 445x107x20
7MBR25SA-120FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 352512000.350.45 445x107x20
7MBR35UA-120FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 352512000.530.37 445x107x20
MIG30J906HTOSHIBAIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 35-6000.250.5 445x107x21
7MBR50SA-060FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 50-6000.450.4 445x107x20
7MBR35SB-120FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 503512000.450.45 462x122x20
7MBR50UA-120FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 503512000.530.37 445x107x20
7MBR75SB-060FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 75-6000.450.4 462x122x20
7MBR50SB-120FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 755012000.350.45 462x122x20
7MBR75U4B-120FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 755012000.40.42 462x122x20
7MBR100SB-060FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 100-6000.450.4 462x122x20
7MBR100U4B-120FUJIIGBtSIX: 3 PHASE BRIDGE (BRAKE+CONVERTER) 1007512000.380.41 462x122x20
(*) : Aislado
Haga click aqui para ver los esquemas...


Módulos Darlington



CODIGO MARCA TIPO CONFIGURACION I (A)
25°c
Vces (V) td(on) (uS)
max.
ts (uS)
max.
tf (uS)
max.
Esquema DIMENSIONES (AxLxH)(mm)
KS524503POWEREXDARLINGTON SINGLE30600 1.5 3.0 537x54x31
KS524505POWEREXDARLINGTON SINGLE50600 1.5 3.0 537x54x31
KS524510
(QM100HY-H)
POWEREXDARLINGTONSINGLE 100 6002.0 3.0 534x95x30
ESM6045AVPOWEREXDARLINGTON SINGLE72 10004.6 0.4 5A24x38x12
KS221K05POWEREXDARLINGTON SINGLE50 10002.5 3.0 634x95x30
KS221K10POWEREXDARLINGTON SINGLE1001000 3.0 3.0 634x95x30
KS621K20POWEREXDARLINGTON SINGLE2001000 3.0 3.0 662x108x42
KS621K30
(QM300HA-2H)
POWEREXDARLINGTON SINGLE3001000 3.0 3.0 662x108x42

KS621K40 (KS621K40A41)

(QM400HA1-2H)

POWEREXDARLINGTONSINGLE 40010003.0  3.0 690x113x36
KD221K03POWEREXDARLINGTON DUAL301000 2.5 3.0 734x95x30
KD221K05POWEREXDARLINGTON DUAL501000 2.5 3.0 734x95x30
KD221K75POWEREXDARLINGTON DUAL751000 2.5 3.0 734x108x37
KD421K10 (QM100DY-2H)POWEREX DARLINGTONDUAL100 10003.0  3.0 762x108x37
KD421K15POWEREXDARLINGTON DUAL1501000 3.0 3.0 762x108x37
KD324510POWEREXDARLINGTON DUAL100600 2.0 3.0 862x95x30
QF15AA60SANREXDARLINGTON SIX: 3 PHASE BRIDGE15600 1.0 2.0 988x39x16
